HYDRAFORCE
5600014

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5600014 (5600014) is a high-performance hydraulic relief valve, specifically designed as a screw-in, cartridge-style valve. The RV0820X model is a direct-acting, poppet type valve, ideal for lower flow circuits that demand minimal internal leakage. It operates by blocking flow from port 1 to port 2 until the pressure at port 1 is sufficient to displace the spring-opposed poppet from its seat. This model boasts several features that enhance its functionality and reliability. Notably, it offers various pressure adjustment options including non-adjustable factory presets and three adjustable settings (A, B, and C) with positive stops to prevent spring compression issues. The valve also supports optional spring ranges up to 248 bar (3600 psi) and responds swiftly to changes in pressure. For applications requiring bidirectional pressure capabilities, an optional bidirectional pressure seal can be added. Its compact design makes it suitable for space-constrained installations. The RV0820X also includes several important notes regarding its application and potential upgrades. It is suggested as a supersession for both existing and new applications with the RVD5820 model cited as an optimal replacement due to its comparable or improved performance metrics such as pressure and flow ratings, response rate, better pressure rise characteristics, smaller size, absence of dynamic seal, and competitive cost considerations. Furthermore, the VC082B cavity variation may be required for this upgrade; however, some manifolds might allow for a drop-in replacement simplifying transition efforts. Assistance is available from Hydraforce to evaluate specific application needs ensuring optimal integration of this hydraulic relief valve into various systems.
